| Lazer Kaynak Türü / Laser Source Type | Multi-Diode Pumped Fiber (Yb) LASER (Class 4) |
| Dalga Boyu / Wave-Length | 1059 ÷ 1065 nm |
| Lazer Darbe Gücü / Laser Pulse Power | 70 W |
| Darbe Süresi / Pulse Time | 200 ns40 ns40 nS12 ÷ 520 ns |
| M² | 1.0 ÷ 1.6 |
| Frekans / Frequency | 1 ÷ 500 kHz |
| Darbe Enerjisi / Pulse Energy | 1.0 mJ at 20 kHz |
| Güç Kaynağı / Power Supply | 1-ph, 230Vac, 50/60Hz, 6A |
| Maksimum Tüketim / Maximum Comsumption | 750 W |
| Boyutlar / Dimensions | 45 x 71 x 65/93 cm |
| Ağırlık / Weight | 75 Kg |
